钣金机箱机柜采用快开侧门，方便安装和维修
The sheet metal chassis and cabinet adopt quick opening side doors for easy installation and maintenance
仿威图机柜的特点：
Features of the imitation Rittal cabinet:
具有良好的技术性能
Having good technical performance
具有良好的使用性和防护设施，便于操作安装和维修，并能确保操作者。
It has good usability and safety protection facilities, which are easy to operate, install, and maintain, and can ensure the safety of operators.
便于生产组装调试和包装运输。
Convenient for production, assembly, debugging, packaging, and transportation.
合乎标准化规格化系列化的要求。
Meet the requirements of standardization, standardization, and serialization.
造型美观适用色彩协调。
Beautiful appearance, suitable for color coordination.
一确定仿威图机箱的类型和外形尺寸
Determine the type and overall dimensions of the imitation Rittal chassis
仿威图机箱类型是在总体布局过程中，根据不同的产品应用需求，制定各种不同方案，经过讨论分析和比较而确定是挂墙式桌面式还是上架式的。
The type of imitation Weitu chassis is determined through discussion, analysis, and comparison during the overall layout process, based on different product application requirements, to develop various solutions and determine whether it is a wall mounted desktop or a shelving type.
机箱尺寸是按机箱内元器件的大小确定初步尺寸，然后根据这个尺寸选用标准尺寸；也可先选定标准的外形尺寸，再进行箱内的元器件布局分配。
The size of the chassis is determined based on the size of the components inside the chassis, and then standard dimensions are selected based on this size; You can also select standard external dimensions first, and then allocate the layout of components inside the box.
二面板设计机箱内元器件的排列布局
Arrangement and layout of components in the two panel design chassis
面板的尺寸是在机箱类型尺寸确定后定下的，而面板上各种操纵和显示装置的选择和布局，应该根据电原理图的要求人机工程造型通风等因素综合考虑。
The size of the panel is determined after the chassis type size is determined, and the selection and layout of various control and display devices on the panel should be comprehensively considered based on the requirements of the electrical schematic diagram, ergonomic design, ventilation, and other factors.
机箱内部元器件的排列是根据电原理图，主要元器件的外形尺寸及相互关系，并考虑通风减振屏蔽及走线的方便美观程度等来确定的。
The arrangement of components inside the chassis is determined based on the electrical schematic diagram, the external dimensions and interrelationships of the main components, and considering the convenience and aesthetics of ventilation, vibration reduction, shielding, and wiring.
三怎样选择好的仿威图机箱机柜
How to Choose a Good Mimic Rittal Cabinet
看钢板，钢板一定要厚，你用手指敲一下，就能感觉到哪些厚哪些薄了。
Look at the steel plate, it must be thick. You can feel which ones are thick and which ones are thin by tapping with your fingers.
看喷漆，一个合格的仿威图机柜，所有的钢材都需要喷漆，而且喷漆一定要平均，这样才能良好地防锈防尘等。
Look at the paint spraying. A qualified imitation Rittal cabinet requires paint spraying on all steel, and the paint spraying must be evenly distributed in order to effectively prevent rust and dust.
看架构布局，一般来说，挡板要多，而且具有散热孔，一些用来固定线缆的铁皮要包边，预防损坏线缆。侧壁风扇应安装在仿威图机柜后壁，由于设备后部产生大多数的热量。
Based on the architectural layout, generally speaking, there should be more baffles and heat dissipation holes. Some iron sheets used to fix cables should be wrapped to prevent damage to the cables. The side wall fan should be installed on the back wall of the simulated Rittal cabinet, as the rear of the equipment generates most of the heat.
看配件，因为安装中包括网络电缆电信电缆和电源电缆，需要购买钩环带或带齿的带子来有效地把电缆有序的固定在仿威图机柜里面。假如仿威图机柜带有电缆治理模块使电缆可以直接固定在垂直安装轨内，则再好不外。
Look at the accessories, as the installation includes network cables, telecommunications cables, and power cables. It is necessary to purchase hook and loop straps or toothed straps to effectively secure the cables in an orderly manner inside the simulated Rittal cabinet. If the imitation Rittal cabinet comes with a cable governance module that allows the cables to be directly fixed in the vertical installation rail, then it is no exception.
看玻璃，玻璃一定要厚一点的，还要留意玻璃的周边是否有裂缝，假如有裂缝，就意味着有隐患了，还有要留意是否棘手。
Looking at the glass, it must be thicker and pay attention to whether there are cracks around the glass. If there are cracks, it means there are hidden dangers, and it is also important to pay attention to whether it is difficult.
看功能：率先考虑的应是性。
Looking at functionality: Safety should be the first consideration.
看散热，估计一下你的设备发热量有多大，一般来说，柜顶都有二到四个风扇，风扇都是多多益善的啦。还有一些用来固定机架的螺丝螺母等，也要足量。不因日后扩展而带来配件不足的麻烦。
Look at the heat dissipation and estimate how much heat your device generates. Generally speaking, there are two to four fans on the top of the cabinet, and the more fans, the better. There are also sufficient screws and nuts used to secure the rack. Not causing trouble with insufficient accessories due to future expansion.
