1. The Rittal cabinet can be divided into three series structurally: ES cabinet (50 fold profile cabinet), PS cabinet (9 fold profile cabinet), and TS cabinet (16 fold profile cabinet). The main feature of Rittal cabinet is that it adopts a profile frame structure. The frame of the cabinet is welded first, and then the board, bottom plate, side plate, door plate, and installation plate are fixed to the frame with screws. This advantage is that the product has a modular structure and is easy to use;

2.产品美观，rittal机柜从工业品的使用和外观上都追求的理念，从钣金结构设计和附件的搭配使用也十分合理科学，形成了标准化的配套设计;

2. The product is beautiful, and Rittal cabinets pursue the concept of perfection in both industrial use and appearance. The design of sheet metal structures and the use of accessories are also very reasonable and scientific, forming a standardized supporting design;

3.使用方便，内部的纵梁、立柱、横梁、走线条及本身的模塑化孔的设计使得用户安装都显得得心应手、方便自如，配上日光灯和行程开关，柜门关上灯灭，柜门开灯亮，使得检修十分方便;

3. Easy to use, the design of the internal longitudinal beams, columns, crossbeams, running lines, and its own molded holes makes installation easy and convenient for users. Equipped with fluorescent lights and travel switches, the cabinet door closes and the light turns off, while the cabinet door opens and the light turns on, making maintenance very convenient;

4.结实耐用、可靠，威图柜框架结构使得结构稳固，单柜大可承重2000KG，不惧安装任何笨重器件;

4. Durable, safe and reliable, the Rittal cabinet frame structure makes the structure stable, and a single cabinet can bear a weight of 2000KG without fear of installing any bulky components;

5.同时仿威图机柜从材料上分别碳钢和不锈钢，料厚默认为门板2.0mm，安装板2.5mm，柜体1.5mm;仿威图机柜

5. At the same time, the imitation Rittal cabinet is made of carbon steel and stainless steel, with a default material thickness of 2.0mm for the door panel, 2.5mm for the installation plate, and 1.5mm for the cabinet body; Mimic Rittal cabinet

6.碳钢的表面处理默认为喷塑处理，喷塑前做磷化底涂处理，颜色为RAL7035，不锈钢的表面处理默认工艺为拉丝处理;

6. The default surface treatment for carbon steel is spray coating, with a phosphating primer treatment before spray coating, and the color is RAL7035. The default surface treatment process for stainless steel is wire drawing treatment;

而一般柜子为冷轧板或者镀锌板焊接，对板材要求和加工的平整度，配件选择都没有严格要求，结构也多半为固定焊接处理，使用起来不灵活。当然也相对便宜很多。

However, general cabinets are made of cold-rolled or galvanized sheet welded, and there are no strict requirements for the flatness of the plate and processing, as well as for the selection of accessories. The structure is mostly fixed and welded, making it difficult to use flexibly. Of course, the price is also relatively much cheaper.

仿威图机柜的意义不是冒牌，而是根据rittal公司的工艺去仿制，而国内有的厂家做出的仿威图机柜在工艺水平上已经赶上或接近威图rittal，同时在货期、服务、上相比rittal公司有很大的优势。

The significance of imitating Rittal cabinets is not to counterfeit them, but to imitate them according to Rittal's technology. Some domestic manufacturers have already caught up with or approached Rittal's imitation Rittal cabinets in terms of technology level, and have significant advantages over Rittal in terms of delivery time, service, and price.

另外在选型仿威图机柜过程中，有些业主硬性要求IP56、IP66防护等级，作为仿威图机柜本身来说，具有较高的防护等级，因为机柜门的密封条都是采用PU发泡工艺，我们则选用的是进口AB料，确保密封条饱满、富有弹性，不易变形等特征。锁具附件采用生久产品，确保产品质量。但是如果项目用于户外、船舶等情况下仅仅依靠柜体本身防护等级还不够，需要我们加配防雨棚，防止较大雨水冲击柜体，从而很好地从仿威图机柜源头解决问题。

In addition, during the selection process of the imitation Rittal cabinet, some owners have mandatory requirements for IP56 and IP66 protection levels. As for the imitation Rittal cabinet itself, it has a higher protection level because the sealing strip of the cabinet door is made of PU foam technology. We choose imported AB material to ensure that the sealing strip is full, elastic, and not easily deformed. The lock accessories are made of Shengjiu brand products to ensure product quality. However, if the project is used outdoors, on ships, and other occasions, relying solely on the protection level of the cabinet itself is not enough. We need to add a rain shelter to prevent heavy rain from impacting the cabinet, so as to effectively solve the problem from the source of the imitation Rittal cabinet.
