MNS低压抽屉柜的配置标准是什么?

发布时间:2022-03-30 来源:http://www.tongyuhengcheng.com/ 浏览量:

  配置标准是一个设备或者机器使用前后需要存在的要求,所以MNS低压抽屉柜也不例外,有了配置标准才能按照标准去做事做计划,这一点挺重要的,那么MNS低压抽屉柜的配置标准是什么?
  Configuration standard is a device or machine before and after the use of the need to exist requirements, so MNS low-pressure chest of drawers is no exception, with the configuration standard in accordance with the standard to do things and plan, this is very important, so what is the configuration standard of MNS low-pressure chest of drawers?
  MNS低压抽屉柜的更换或安装前,应检查元件铭牌和线圈上的数据,空气开关的脱扣器类型和附件是否符合图纸的电路要求。
  Before replacing or installing MNS low-voltage cabinet of drawers, check the data on the component nameplate and coil, the type of release device and accessories of the air switch to see if they meet the circuit requirements of the drawings.
  合理拧紧MNS低压抽屉柜的各部件或按原位拧紧,并用紧固件拧紧。拧紧应按一定顺序进行。例如,四个角拧紧时,应成对进行。
  Reasonably tighten the components of MNS low-pressure drawer cabinet or tighten them in situ and tighten them with fasteners. Tightening should be carried out in a certain order. For example, tightening of four corners should be done in pairs.
  安装或更换时,根据元件说明书调整元件(如热继电器)的参数。元件应固定在坚固的骨架、支架或安装板上,固定螺钉应拧紧,不得滑脱和松动。螺丝拧紧后,螺纹应露出螺母的2-5个螺纹,尽量不超过8个螺纹。
  During installation or replacement, adjust the parameters of components (such as thermal relays) according to their specifications. The components should be fixed on a solid skeleton, bracket or mounting plate, and the fixing screws should be tightened without slipping or loosening. After the screw is tightened, two to five threads of the nut should be exposed, and no more than eight threads should be exposed.
  安装的部件与加热设备之间应有一定的距离(必要时考虑隔热措施)。在元器件或布线的布置中,不同极性外露的带电导体之间应保证一定的距离,以防止发生短路事故(必要时应加绝缘处理)。
  There should be a certain distance between installed parts and heating equipment (consider insulation measures if necessary). In the layout of components or wiring, a certain safe distance should be kept between live conductors with different polarity exposed to prevent short circuit accidents (insulation treatment should be added if necessary).
  主电路绝缘线一般采用黑线,接地保护采用黄绿双色线。请注意,接线时,请勿使用虎钳、尖嘴钳等强行拉直电线。线材应戴手套拉直,不得用螺丝刀、尖嘴钳等强行将线束挤入线槽。
  The insulation wire of the main circuit is usually black, and the ground protection is yellow and green. When connecting cables, do not use vice or needle-nose pliers to straighten the wires. The cables should be straightened with gloves. Do not squeeze the cable bundle into the cable trough by force with a screwdriver or needle-nose pliers.
  当需要改变接线方向时,只能手动操作,不能使用尖嘴钳。用虎钳等锋利的工具强行弯曲,以确保电线绝缘层不被损坏。
  If you need to change the direction of the cable connection, do not use the needle-nose pliers. Use a sharp tool, such as a vise, to force the bending to ensure that the insulation of the wire is not damaged.
  MNS低压抽屉柜的配置标准是什么?以上便是问题的解答内容了,那么如果对此您还有什么要问的话,可以来http://www.tongyuhengcheng.com我们网站咨询人员,为您解答疑惑。
  What is the configuration standard of MNS low pressure chest of drawers? This is one problem solution content, so if this what you want to ask, can come to our website http://www.tongyuhengcheng.com consulting professionals, answer for you.
