电子机箱机柜特殊性能要求有哪些?

发布时间:2021-09-10 来源:http://www.tongyuhengcheng.com/ 浏览量:

电子机箱机柜的特殊工作性能导致了对体积、功耗、发热量等物理参数的选择,因为电子机箱机柜通常用于在大型机房中部署和管理大量的设备资源.机房通常配备严格的
The special working performance of electronic cabinet leads to the selection of physical parameters such as volume, power consumption and calorific value, because electronic cabinet is usually used to deploy and manage a large number of equipment resources in large computer rooms. Computer rooms are usually equipped with strict
措施,良好的空调系统等。
Measures, good air conditioning system, etc.
那么我们如何在有限的空间内部署更多的设备?
So how can we deploy more equipment in limited space?
机架式电子机箱机柜通常选用机械尺寸符合19英寸工业标准的机柜。
Rack type electronic cabinet usually adopts the cabinet whose mechanical size meets the 19 inch industrial standard.
机架式设备也有多种规格,如1U4.45cm高、2U、4U、6U、8U等
Rack mounted equipment also has a variety of specifications, such as 1u4.45cm high, 2U, 4U, 6U, 8U, etc
一般为1U机架式电子机箱机柜节省空间,但性能和扩展性较差,适用于一些相对固定的业务区域。
Generally, 1U rack type electronic cabinet saves space, but its performance and scalability are poor. It is suitable for some relatively fixed business areas.
4U以上的产品具有更高的性能和良好的扩展性,一般支持4个以上的高性能处理器和大量标准的热插拔组件。
Products above 4U have higher performance and good scalability, and generally support more than 4 high-performance processors and a large number of standard hot plug components.
管理也很方便,适合访问量大的重点应用,但是体积大,空间利用率不高。
Management is also very convenient, suitable for key applications with large visits, but the volume is large and the space utilization is not high.
1机柜与机柜之间的走线一般从机柜顶部走线。
1 the wiring between cabinets is generally routed from the top of the cabinet.
济南机箱机柜
2必须打开机柜的空调挡板,防止设备过热导致死机。
2. The air conditioning baffle of the cabinet must be opened to prevent the equipment from overheating and causing crash.
3电缆两端应贴标签,标明编号,标签写清楚。
3 both ends of the cable shall be labeled with the number, and the label shall be clearly written.
4如果机柜是内外网交换机,尽量用两种不同颜色的网线来区分。
4 if the cabinet is an internal and external network switch, try to distinguish it with two different colors of network cables.
5对于固定安装机柜,机柜内不应有预留电缆长度。对于移动式机柜,所有连接机柜的电缆应在机柜入口处至少预留1m。
5 for fixed installation cabinet, there shall be no reserved cable length in the cabinet. For mobile cabinet, all cables connecting the cabinet shall be reserved at least 1m at the entrance of the cabinet.
6不同电压等级、不同电流等级的线路应分开布置,分开敷设
6 lines with different voltage levels and current levels shall be arranged and laid separately
7.电缆中间不允许有接头
7. No joint is allowed in the middle of the cable
8机柜接线时,请确保电源线插头和服务器电源连接器两端用标签扎带固定。
8 when wiring the cabinet, please ensure that both ends of the power cord plug and the server power connector are fixed with label ties.
9粘贴每台服务器的资产编号,通过标签打印机将资产编号+条码一起打印出来。每台服务器上都印有两份相同的副本,分别在设备正面和侧面。电子机箱机柜的信号强度和表面处理
9 paste the asset number of each server and print the asset number + barcode together through the label printer. Two identical copies are printed on each server, on the front and side of the device. Signal strength and surface treatment of electronic cabinet
